Uno Dock v2.0 for NanoPi NEO/Air/NEO2

News2017-04-24
Auhtor: Petr Šrámek

New version of dock for single-board computer NanoPi NEO/Air/NEO2.

It combines power of NanoPi NEO/Air/NEO2 and fast development of arduino on one board.

The board contains headers compatible with arduino uno rev3 and NanoPi NEO/Air/NEO2.

On the board are also USB-Serial convertor, 12V power supply, 2x USB 2.0 host.

It supports BakeBit modules.

The dimension od Uno Dock is 110.2 x 53.3 mm.

The price is $6.99 + shipping. Link http://www.friendlyarm.com/index.php?route=product/product&product_id=188
