A64_OLinuXino – quad-core, 1/2GB RAM, WiFi&BLE, gigabit ethernet

News2017-06-06
Auhtor: Petr Šrámek

Olimex released a new single-board computer – A64-OLinuXino. THe development of board started since 2015, now is available on store.

A64-OLinuXino is available in three variants. On store is only A64-OLinuXino-1G4GW now.
A64-OLinuXino-1G0G: The first, the cheapest (40 EUR), contains 1GB RAM, doesn’t include FLASH eMMC memory and WiFi&BLE connectivity as well.

A64-OLinuXino-1G4GW: More expensive (50 EUR) contains 1GB RAM, includes 4GB FLASH eMMC memory and WiFi&BLE connectivity as well.

A64-OLinuXino-2G16G-IND: The most expensive variant (75EUR) has 2GB RAM, 16GB FLASH eMMC memory, WiFi&BLE and the board is designed for industrial temperature range -40+85 ?C.

All of them contains Allwinner A64 – 1.2 GHz Quad-Core ARM Cortex-A53 64-bit, DDR3L RAM @ 672MHz, microSD slot (supports up to 32 GB), UART debug port, 10/100/1000 ethernet, HDMI output for monitor, audio autput and input for microphone.

A64-OLinuXino can be powered through 5V power supply, 3.7V LiPo battery (deska obsahuje nab?jec? obvod), USB A, LED, 40pin header, 10pin header, RTC, and you can solder SPI FLASH memory in SO8 package.

The dimension is 90.0 x 62.5 mm.

Link to store https://www.olimex.com/Products/OLinuXino/A64/A64-OLinuXino/open-source-hardware

Github of project: https://github.com/OLIMEX/OLINUXINO/tree/master/HARDWARE/A64-OLinuXino
