PHOTO GALLERY: STEVAL-WESU1 – wearable sensor unit

News2016-05-19
Author: Petr Šrámek

STMicroelectronics released wearable unit. It contains a lot of sensors. The data are sent to mobile phone through bluetooth. App is available on Apple Store? and Google Play?.

App is based on BlueST SDK, available on GitHub.

What contains this device:
STM32L151VEY6 ? 32-bit ultra-low-power MCU

LSM6DS3 ? 3D accelerometer + 3D gyroscope

LIS3MDL ? 3-axis magnetometer

LPS25HB ? MEMS pressure sensor

BlueNRG-MS ? BLE network processor

BALF-NRG-01D3 – 50 ? balun with integrated harmonic filter

STNS01 ? Li-Ion linear battery charger

STC3115 ? Fuel gauge IC

100 mAh Li-Ion battery included, UN38.3 tested and certified

Micro USB connector for recharging

SWD connector for debugging and programming capability

Another information: http://www.st.com/content/st_com/en/products/evaluation-tools/solution-evaluation-tools/sensor-solution-eval-boards/steval-wesu1.html?icmp=tt3606_gl_bn_may2016
