PMOD HAT for Raspberry Pi

News2018-01-22

If you like PMOD modules by Digilent, maybe you welcome this new board which is called Pmod HAT Adapter: Pmod Expansion for Raspberry Pi. The PMOD HAT (HAT, shield, exapansion board) is available for Raspberry Pi all types (A+, B+, 2 B, 3 B, Zero W, Zero).

The expansion board with PMOD connectors contains 40 pin header which you easy connect to Raspberry Pi. The board also contains DC connector for powering.

The board contains standard Raspberry Pi connector which includes a lot of other single-board computers like (Banana Pi, Orange Pi, Nano Pi, …).

The board supports SPI, I2C, UART and GPIO. The board includes three PMOD connectors.

Python library is available for this board.

The dimension of board is 65 x 56.5 mm.

The price of board is 15 USD on digilent store, or you can buy it on RS-Online for 14 GBP.

The news shared Linux Gizmos
