Raspberry Pi + Arduino + Bluetooth 4.0 + WiFi + Accelerometer + Magnetometer + Digital Gyroscope = UDOO NEO

News2015-12-05
Auhtor: Petr Šrámek

UDOO NEO is an open hardware low-cost computer equipped with a FreescaleTM i.MX 6SoloX applications processor for Android and Linux.

The processor embeds an ARM? Cortex?-A9 and Cortex-M4 microcontroller which makes the board compatible with the Arduino environment allowing high performance at a low price.

Arduino compatible pinouts, 3-axis accelerometer, 3-axis digital gyroskope, 3-axis magnetometer, WiFi802.11b/g/n, Bluetooth 4.0 Low Energy.

512MB or 1GB DDR3 RAM (Plus version)

HDMI interface,

SPI Flash onboard,

1x USB 2.0 a 1x USB OTG

Ethernet 10/100

3x UART, 2x CAN

8x PWM, 1x I2C, 1x SPI

36 GPIOs

http://www.udoo.org/udoo-neo/
