UPDATED: Orange Pi WIN – SBC for $25

News2017-03-10
Auhtor: Petr Šrámek

Pictures of new version of single-board computer called Orange Pi WIN.

The price of Orange Pi WIN is $25 (+ shipping).

You find on the board:

A64 quad-core Cortex-A53

Mali400MP2 GPU

1GB DDR3 shared with GPU

TF card (max 64GB) / NOR flash 2MB / eMMC

RJ45 1000/100Mb ethernet

CSI camera input

support of HDMI and MIPI LCD

audio v?stup 3.5mm jack

WiFi & BT onboard (AP6212, IEEE 802.11 b/g/n, BT4.2)

4x USB2.0, 1x USB 2.0 OTG

40pin header compatible with RPi B+

Power supply: DC vstup, USB OTG or battery input

OS: Android, Debian, Ubuntu, Raspberry Pi Image

You can buy it on aliexpress.com https://www.aliexpress.com/store/product/Orange-Pi-Win-Development-Board-A64-Quad-core-Support-linux-and-android-Beyond-Raspberry-Pi-2/1553371_32798200305.html
